SPC Flooring
Description
This is an innovative product upon LVT. It has an interlocking click system which creates a 100% water-tight surface. This solves the shrinkage problem, and make vinyl flooring truly water-proof. The printing film can imitate from wood to carpet, from ceramic to cement. The installation is floating type by no glue – and also no formaldehyde. However, it requires the installation to strictly follow the rules of the click system.
Technical Data
| Test Items | Test Standards | Test Results |
| Residual Indentation | 0.15<Is≤0.40 | 0.16 |
| Flammability | B1 | |
| Peel Strength | N/50mm | (average)≥75 |
| (minimum)≥70 | ||
| Click Strength | KN/m | ≥1.5 |
| Size Change Rate After-heating | Longitudinal≤0.25% | Length: -0.10 |
| Horizontal≤0.25% | Width: -0.07 | |
| Size Change Rate After Heating | Average∆E* ≦8.0 | 0.09 |
| Formaldehyde Emission | ≤0.124 mg/m³ | 72h Not Detected |
| Total Volatile Limit | ≤10 g/m³ | 4.9 |
| Phthalic Plasticiser | ≤0.1% | Not Detected |
Detail
Production Process
RAW MATERIAL MIXING
Blend PVC resin, stabilizers, fillers, and additives in precise ratios using high-speed mixers to ensure uniformity.
HOT MELTING
Heat the mixed materials to 180-200°C in extruders, turning them into a homogeneous molten mass.
EXTRUSION MOLDING
Force the molten material through a die to form continuous panel blanks with fixed cross-sections.
SURFACE PRINTING/LAMINATION
Apply decorative patterns via roller printing or laminate with PVC films for aesthetics.
COOLING & SIZING
Cool the panels with water to stabilize dimensions, ensuring straightness and precise thickness.
CUTTING TO LENGTH
Cut the continuous panels into specified lengths (e.g., 2440mm) with precision saws.
PACKING
Wrap panels with PE film and pack on pallets to protect against scratches and moisture.
LOADING & SHIPPING
Load palletized products into containers, securing them for safe transportation.
Quality Control & Packing
