FILM FACED PLYWOOD is also called formwork plywood, shuttering plywoods, concrete form. Film faced plywood is the special plywood with two sides coated with wearable and water proof film. The film is adhesive impregnated paper, which are different from melamine paper overlay, PVC, MDO (MDO plywood) and HDO (HDO plywood). The function of the film is to protect the inside wood from moisture, water, weather and extend the plywood’s service life. Film faced plywood can be used in harsh and outside environment: shuttering plywood, formwork plywood, concrete formwork, floorboard, vehicle building.
Water Proof Film Faced Plywood is polished on both sides, so its surface is smooth, hard and durable. Plywood is characterized by excellent strength and rigidity, so it performs well in applications that require high strength and rigidity. Waterproof plywood also has good resistance to moisture, and is easy to machine and handle. By using different types of veneers, the surface characteristics of the plywood can be further enhanced.
Water Proof Film Faced Plywood has high weight-to-strength ratio and high durability. Moreover, it is easy to machine, easy to use standard mechanical trimming and standard method to fix. There are a wide range of film varieties and sizes to choose from. Better non-slip performance is suitable for floor applications. We can provide customized specifications and mechanical processing services, as well as high-quality technical services.
세부 정보
생산 프로세스
RAW MATERIALS STORAGE
We have several warehouses to store all our Raw Materials like Poplar Veneer, Hardwood Veneer, Sapelli/Bintangor/Okoume/Pencil Cedar/Pine Face/Back, etc. Once new raw materials delivered into our warehouses, our workers will inspect all and place different grade ram materials into different warehouses.
RAW MATERIALS PRETREATMENT
Once production started, our workers will pretreat the raw materials including the sides joint, gluing.
VENEERS ASSEMBLE
Our workers will assemble the wood veneers one layer by one layer on the assembly line. Like the 18MM will consist of 11 layers wood veneers.
RAW BOARDS PREPRESS
After Veneer Assemble Process, all the Raw Boards need to be prepressed by Cold Press Machine. So that the Raw Boards can be shaped into Raw Plywood. This process need at least 2 hours.
RAW PYWOOD HOT PRESS
Shaped Raw Plywood will be laminated by Hot Press Machine. This process need at least 1 hour. After Hot Press, the Raw Plywood bonding will be strong.
RAW PYWOOD REPATCHING & PUTTYING
This process is to fill the gap on the surface of raw plywood.
RAW PYWOOD SANDING
Put the Raw Plywood into Sanding Machine. After sanding, the raw plywood surface become smooth, and thickness will be even also.
FACE/BACK VENEER ASSEMBLE
Raw Plywood will be glued firstly. Then workers will place the face/back veneer like Sapelli /Bintangor/Okoume/Pencil Cedar on the both sides of raw plywood.
COLD PRESS
After Face/Back Veneer Assemble Process, plywood will be placed into Cold Press Machine again. So that the Face/Back Veneer will bond with the raw plywood initialy. This process need at least 1 hour.
LAMINATED PYWOOD HOT PRESS
This process need at least 30 minutes. After second Hot Press, Face/Back Veneer will bond with the raw plywood strong.
CUTTING & POLISHING
All plywood will be cut into standard size like1220X2440MM. Then plywood will be polished gain to make the face/back smooth.
INSPECTION & PACKING
Inspect boards for defects (e.g., cracks, uneven density, surface imperfections). Grade the qualified boards based on quality standards. Stack and package the boards for storage or shipment.
